MODEL: DN-170096TECHNICAL DETAILS : ONLINE DOUBLE CONVERSION SYSTEM (VFI-SS-111), INPUT: SOCKET IEC60320 C20, 208/220/230/240 VAC, OUTPUT: 8 X IEC60320 C13, MAX. 10A PER SOCKET 1 X IEC60320 C19, MAX. 16A PER SOCKET, SYSTEM POWER RATING: 3000 VA / 3000 W, POWER FACTOR 1.0, AC-AC (ONLINE VFI) EFFICIENCY: 93 %, ECO MODE EFFICIENCY: 98 %., REPLACEABLE INTERNAL BATTERY PACK DURING OPERATION., BATTERY: VALVE-REGULATED, NON-SPILLABLE LEAD-ACID BATTERY., BATTERY CAPACITY: 6 X 12V X 9.0 AH, FULL LOAD RUN TIME: 3 MIN HALF LOAD RUN TIME: 9 MIN, CHARGE: 4 HOURS TO 90% CAPACITY AFTER FULLY DISCHARGED, EXTERNAL BATTERY MODULES AVAILABLE (PART NUMBER: DN-XXXXX), UP TO 4 ECB CONNECTABLE, NETWORK CONNECTION: OPTIONAL SNMP/WEBCARD (PART NUMBER DN-170100) ALLOWS REMOTE MONITORING OF THE UPS., OPTIONAL RELAY CARD (PART NUMBER DN-XXXXX) WITH POTENTIAL FREE INPUTS AND OUTPUTS (BYPASS, UPS ON, AC ERROR, BATT LOW, UPS ALARM), LOCAL COMMUNICATION PORTS: USB, RS-232 (SERIAL), SNMP CARD (OPTIONAL), RELAY CARD (OPTIONAL), EMERGENCY POWER-OFF (EPO) CONTACT FOR UPS SHUTDOWN IN CASE OF EMERGENCY, MAXIMUM OPERATING TEMPERATURE: 0 – 40 °C, STORAGE TEMPERATURE: -25 – 55 °C, RELATIVE HUMIDITY: 20 – 90% NON-CONDENSING, OPERATING ALTITUDE: < 1500 M, PRODUCT DIMENSIONS WXDXH (MM): 440 (19") X 600 X 86.5 (2U), PRODUCT WEIGHT: 26 KG, SHIPPING DIMENSIONS WXDXH (MM): 560 X 730 X 200, SHIPPING WEIGHT: 30.2 KG, SAFETY STANDARDS: IEC/EN62040-1,IEC/EN60950-1, EMC STANDARDS: IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8, APPROVAL: CE DECLARATION, SCOPE OF DELIVERY: UPS UNIT, FEET FOR TOWER INSTALLATION, UPS MANUAL, UPS QSG, UPS SOFTWARE LICENSE, USB CABLE, MAINS CABLE (1.8M PROTECTIVE CONTACT SOCKET (TYPE 7/4) TO IEC60320 SOCKET C20), IEC C13 CONNECTION CABLE, 19" INSTALLATION BRACKETS, OPTIONAL AVAILABLE: 19" UPS MOUNTING KIT (PROFILE RAILS), PART NUMBER DN-170109, INSTALLATION: DESKTOP, RACK, PLUG: IEC 60320 C20 INLET, POWER: 1500VA 3000VA, TECHNOLOGY: ONLINE DOUBLE CONVERSION, INCH FORM FACTOR (IEC 60297): 482.6 MM (19")
