SFTP KABL CAT 8.2 LSOH 100M DK-1843-VH-1

MODEL:.DK-1843-VH-1PHYSICAL PROPERTIES:CONDUCTOR: BARE ANNEALED COPPER, SOLID AWG 22/1INSULATION: SFS-PE (FOAMED POLYETHYLENE SHEATH)TOTAL NUMBER OF INSULATED CONDUCTORS: 8, TWISTED IN 4 PAIRSCOLOR CODE: BLUE-WHITE, ORANGE-WHITE, GREEN-WHITE, BROWN-WHITESHIELDING OF THE INDIVIDUAL PAIRS: ALUMINUM-COVERED POLYESTER FILM, 100% COVERAGEOVERALL SHIELDING: TINNED COPPER WIRE BRAIDOUTER SHEATH: DCA ACC. TO EN 50575 LSZHOUTER SHEATH DIAMETER (NOMINAL): 0.55 MM NOMINALOUTER SHEATH COLOR: YELLOWMECHANICAL PROPERTIES:TENSILE LOADING: 150N MAX.DYNAMIC BENDING RADIUS: 8X AD MM MIN.STATIC BENDING RADIUS: 4X AD MM MIN.TRANSPORT AND STORAGE TEMPERATURE RANGE: -20 °C TO +75 °COPERATING TEMPERATURE RANGE: -20 °C BIS +60 °CINSTALLATION TEMPERATURE RANGE: 0 °C TO +50 °COVERALL DIAMETER SIMPLEX (NOMINAL): 7.9 MM NOMINAL (DCA)WEIGHT (KG/KM): 65 KG/KMELECTRICAL PROPERTIES:
